Summit 30 inch wide built-in undercounter dual zone wine and craft beer cooler with locks, digital controls, and LED lighting, 7.61101e+011, SWBV3071
$1,719.96
Retail Price: $2,555.00
Shipping: $150
$ 1,719.96
Description
SUMMIT's collection of built-in undercounter wine cellars offers quality storage with user-friendly convenience and elegant style.
The SWBV3071 is a 30" wide wine and craft beer cooler designed for built-in installation under counters. The fully finished black cabinet also allows freestanding use. This unit includes two stainless steel trimmed glass doors with a unique French door swing. Both include factory installed locks and professional handles. Front locks offer keyed security for both compartments. The sealed back design ensures easier cleanability.
Two separate zones feature independent digital thermostats, allowing you to store craft beer or white wine in the left side while preserving your red wine in the right. The left beverage compartment includes three slide-out black wire shelves with wooden trim to match the six wooden shelves included in the right. Both sections feature a slotted floor to hold additional bottles. The digital control panel features an LED temperature readout in Celsius or Fahrenheit. Recessed LED lighting in a white hue offers an attractive and efficient presentation.
With its attractive style and user-friendly features, the SWBV3071 is a great addition to any home looking to bring versatile beverage storage under the counter.
Nominal Height: 34
Height of Cabinet: 34
Height to Hinge Cap: 0
Nominal Width: 30
Width: 29.5
Width with Door Open: 0
Nominal Depth: 24
Depth: 23.5
Depth with Handle: 25.25
Depth with door at 90°: 37
Capacity: 5.8
Bottles: 0Defrost Type: AutomaticDoor: GlassCabinet: BlackUS Electrical Safety: ETLCanadian Electrical Safety: ETL-CSanitation: N/AVoltage/Frequency: 115 V AC/60 HzParts & Labor Warranty: 1 YearCompressor Warranty: 5 Years
SPECIFICATIONS
Overview
Nominal Height 34.0" (86 cm)
Height of Cabinet 34.0" (86 cm)
Nominal Width 30.0" (76 cm)
Width 29.5" (75 cm)
Nominal Depth 24.0" (61 cm)
Depth 23.5" (60 cm)
Depth with Handle 25.25" (64 cm)
Depth with door at 90° 37.0" (94 cm)
Capacity 5.8 cu.ft. (164 L)
Defrost Type Automatic
Door Glass
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.5
Voltage/Frequency 115 V AC/60 Hz
Weight 132.0 lbs. (60 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101050423
Wine Cellar
Number of Zones 2
Door Swing French
Adjustable Shelves Yes
Shelf Type Wire and Wood
Shelf Qty 9
Thermostat Type Digital
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.23 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 26.38" (67 cm)
Interior Width 1 12.0" (30 cm)
Interior Depth 1 17.5" (44 cm)
Compressor Step Height 3.0" (8 cm)
Compressor Step Width 26.75" (68 cm)
Compressor Step Depth 5.0" (13 cm)
Level Legs 2
Temperature Range Left side: 36º to 43ºF; Right side: 41º to 72ºF
Interior Height 2 24.75" (63 cm)
Interior Width 2 12.0" (30 cm)
Interior Depth 2 17.5" (44 cm)
Sabbath Mode Yes
FEATURES
Commercial design Meets UL-471 commercial standards
Built-in capable Make the best use of space by installing this unit under the counter
Dual zone design Two independent zones allow you to store both red and white wine or craft beer at the proper conditions
Digital controls Interior digital thermostat lets you separately manage the temperature of each section, with a readout viewable in Celsius or Fahrenheit
Generous storage capacity Store up to 33 standard Bordeaux style wine bottles in the right section and up to 72 8 oz. cans or 48 12 oz. bottles in the beverage section. To accommodate wider Burgundy style wine or champagne bottles, you can remove every other wine shelf
Recessed LED lighting Gentle and energy efficient LED lighting in an attractive white hue offers an elegant view of stored items
Adjustable wooden shelves Red wine section includes six removable wooden shelves for proper bottle storage
Adjustable beverage shelves Craft beer section is equipped with three adjustable black wire shelves with an attractive wooden trim to complement the wine section
Slotted floors Floor is specially designed with slots to allow you to store larger champagne or Burgundy style bottles safely on their sides
Professional handles Sleek stainless steel handles add an elegant touch to any setting
Glass doors French door swing offers a modern look, with stainless steel door trim for an added accent
Factory installed locks Keyed locks on both zones offer separate security for interior contents
Automatic defrost Reduced user maintenance with automatic defrost
Fan-forced cooling Internal fans ensure both interiors have a consistent temperature from top to bottom
Sabbath mode Setting allows you to disable the digital displays, lights, and alarms for religious observance.
High temperature alarm Audible alarm sounds if the interior temperature rises above the recommended range
Open door alarm Alarm will sound if either door is left open for over 60 seconds
Temperature memory function In the event of power loss, the unit will retain its last temperature settings upon power recovery
Sealed back Space-saving design with no exposed coils in the rear offers easy cleanability
Right angle plug Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Fully finished cabinet Allows the unit to be used freestanding
100% CFC free Environmentally friendly design without ozone-damaging chemicals
CARB Compliant Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
DOWNLOADS
BROCHURE w/ DRAWINGS (SWBV3071.pdf)
TECHNICAL DRAWING (.dwg) (SWBV3071_WINE_BEVER._CENT.__A-C_2000_.dwg)
REVIT MODEL (QF_Summit_SWBV3071_Undercounter_Dual_Zone_Wine.rfa)
USE & CARE (SWBV3071-User-Manual.pdf)
