Summit 19 inch wide shallow depth indoor/outdoor beverage center with panel-ready glass door and white interior, 7.61101e+011, SPR489OSCSSPNR

Summit's line of built-in undercounter outdoor appliances includes slim-fitting display beverage centers designed for optimum storage and product presentation.

The SPR489OSCSSPNR features a versatile design that meets NSF-7 and UL-471 commercial standards, but is also approved for residential use. Sized with a slim 19" width and 17 3/4" shallow depth, it features a stainless steel wrapped cabinet with a sealed back for safe installation in the outdoors. The height can be adjusted between 33 7/8 and 34 1/2"es to best suit your space. The double pane tempered glass door includes a panel-ready trim that lets you create a custom look to match or complement other cabinetry (panel dimensions: 18 3/4" W x 31 9/16" H at a minimum of 3/4"es thick). Customers supply their own handle to best match their setting. The space-saving right angle plug and integrated hinge offer added space savings, while the stainless steel kickplate completes the look.

Inside, the SPR489OSCSSPNR utilizes an internal fan to ensure the interior is evenly cooled from top to bottom. An automatic defrost system allows for minimal user maintenance, while the white interior and LED lighting allows full visibility of stored items. Three adjustable glass shelves with six positions provide optimal storage capacity inside the 3.1 cu. ft. interior. The dial thermostat, with seven temperature settings, is located in the upper-right corner for easy temperature management.

The SPR489OSCSSPNR can be installed indoors or outdoors and is designed for built-in or freestanding use. Additional panel-ready choices are available in 15", 18", and 24" wide fits. Browse our full selection to find the perfect fit. Nominal Height: 34
Height of Cabinet: 34
Height to Hinge Cap: 0
Nominal Width: 19
Width: 19
Width with Door Open: 0
Nominal Depth: 18
Depth: 17.75
Depth with Handle: 0
Depth with door at 90°: 34.75
Capacity: 3.13
Bottles: 0Defrost Type: AutomaticDoor: Glass/Panel-Ready FrameCabinet: Stainless SteelUS Electrical Safety: ETLCanadian Electrical Safety: ETL-CSanitation: ETL-SVoltage/Frequency: 115 V AC/60 HzParts & Labor Warranty: 1 YearCompressor Warranty: 5 Years

SPECIFICATIONS

Overview

Nominal Height 34.0" (86 cm)

Height of Cabinet 34.0" (86 cm)

Nominal Width 19.0" (48 cm)

Width 19.0" (48 cm)

Nominal Depth 18.0" (46 cm)

Depth 17.75" (45 cm)

Depth with door at 90° 34.75" (88 cm)

Capacity 3.13 cu.ft. (89 L)

Defrost Type Automatic

Door Glass/Panel-Ready Frame

Cabinet Stainless Steel

US Electrical Safety ETL

Canadian Electrical Safety ETL-C

Sanitation ETL-S

Energy Usage/Year 285.0kWh/year

Amps 1.3

Voltage/Frequency 115 V AC/60 Hz

Weight 85.0 lbs. (39 kg)

Parts & Labor Warranty 1 Year

Compressor Warranty 5 Years

UPC 761101075082

Refrigerator Features

Door Swing RHD

Reversible Factory Reversible

Height Adjustable Yes

Shelf Type Glass

Shelf Qty 3

Adjustable Shelves Yes

Can Storage Yes

Thermostat Type Dial

Fan Type Interior

Refrigerant Type R600a

Refrigerant Amount 0.88oz.

High Side PSI 320.0

Low Side PSI 120.0

Level Legs Qty 2

Interior Light Yes

Temperature Range 34 to 50ºF

Sound Level 32.6 dB

Dimensions

Interior Height 29.0" (74 cm)

Interior Width 16.0" (41 cm)

Interior Depth 12.75" (32 cm)

Compressor Step Height 7.0" (18 cm)

Compressor Step Width 16.0" (41 cm)

Compressor Step Depth 6.25" (16 cm)

FEATURES

Shallow depth Unique 17 3/4" depth is ideal for home wet bars, island kitchens, and other applications with limited footprint space

Built-in capable Make the best use of space by installing your refrigerator under the counter

Panel-ready door trim Door frame can be customized with a custom overlay panel (panel frame dimensions: 31 9/16" H x 18 3/4" W at 3/4" minimum thickness)

Weatherproof design Approved for use in the outdoors, with a sealed exterior and double pane tempered glass door

Commercially approved ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings

Stainless steel wrapped exterior Cabinet features 304 grade stainless steel construction for added durability and a professional look

Double pane tempered glass door Heat resistant design provides clear view of stored products

Automatic defrost Reduced user maintenance with auto defrost system

Adjustable shelves Three glass shelves with six positions for optimal storage and easy cleaning

LED lighting Automatically illuminates when the door is open for an attractive and energy efficient view

White interior finish White interior offers improved visibility of stored contents

Adjustable thermostat Dial thermostat with seven temperature settings offers easy temperature management

Versatile construction Meets both residential and commercial standards

Sealed back Space saving design with easier cleanability and added protection from the elements

Right-angle plug Provides flexibility in unit placement without needing added depth

Factory installed lock Door includes a lock and key for optional security. If planning to use the lock, be sure to include a 5/8" hole in the lower center of your custom panel

Height adjustable Four leveling legs allow you to adjust the height between 33 7/8" and 34 1/2" to best fit your undercounter space

Fully finished cabinet Allows the unit to be used freestanding

100% CFC free Environmentally friendly design does not contain ozone-damaging chemicals

CARB Compliant Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

DOWNLOADS

BROCHURE w/ DRAWINGS (SPR489OSCSSPNR.pdf)

TECHNICAL DRAWING (.dwg) (SPR488BOSCSSPNR_SPR489OSCSSPNR_3.dwg)

ASSEMBLY DRAWING (SPR488BOSCSSPNR_SPR489OSCSSPNR-Assembly_3.pdf)

USE & CARE (SPR489OSCSSPNR-User-Manual.pdf)

SUPPORT (707.bin)

Energy Guide
