Summit Commercially approved frost-free reach-in freezer in complete stainless steel, left hand door swing, 7.61101e+011, SCFF237LH

Summit Commercial's line of reach-in refrigeration features durable construction built to NSF-7 commercial standards.

Made in South Korea, the SCFF237LH is a commercial all-freezer with a complete stainless steel cabinet. The stainless steel door features a self-closing design to help protect stored contents in busy commercial settings where customers may not take the time to make sure the door is closed. It will remain open when pushed to 90º, making it easier to load and unload the unit. The sealed back design helps to simplify cleanup. This unit features a factory-installed lock located towards the top of the door for convenient security. We include a set of locking casters for optional installation. The door has a left hand swing. For the same unit with the door opening from the other side, see the SCFF237.

The SCFF237LH features a large 23 cu.ft. interior constructed from stainless steel for easy cleanup and lasting durability. The cantilevered shelving system allows you to adjust the four vinyl-coated shelves to virtually any position, making it easy to accommodate any sized item. This unit is designed to fit common commercial baking trays. The LED lighting offers an energy efficient display when the door is opened. This unit utilizes adjustable cycle defrost operation to avoid temperature spikes, with a top-mounted forced air cooling system to ensure rapid temperature recovery.

To ensure optimum storage conditions, the SCFF237LH is equipped with a microprocessor temperature controller that makes it easy for staff to adjust the temperature. The large digital LED readout displays the current and high/low temperatures in Celsius or Fahrenheit. An audible and visual temperature alarm sounds if the unit rises or falls above a user-set range. Additional alarms include a power failure alert, door open alarm, and a condenser cleaning reminder.

Designed with hydrocarbon refrigerant, the SCFF237LH provides an energy efficient solution to large capacity storage. It is ETL-S listed to NSF-7 commercial standards. For a matching refrigerator, see the SCRR232.

SPECIFICATIONS

Overview

Nominal Height 84.0" (213 cm)

Height of Cabinet 83.75" (213 cm)

Nominal Width 28.0" (71 cm)

Width 27.5" (70 cm)

Nominal Depth 31.0" (79 cm)

Depth 31.0" (79 cm)

Depth with door at 90° 56.5" (144 cm)

Capacity 23.0 cu.ft. (651 L)

Defrost Type Frost-Free

Door Stainless Steel

Cabinet Stainless Steel

US Electrical Safety UL

Canadian Electrical Safety ULC

Sanitation ETL-S

Amps 8.0

Voltage/Frequency 115 V AC/60 Hz

Weight 273.0 lbs. (124 kg)

Parts & Labor Warranty 2 Years

Compressor Warranty 5 Years

UPC 761101066769

Freezer

Door Swing LHD

Reversible No

Interior Height 51.5" (131 cm)

Interior Width 23.5" (60 cm)

Interior Depth 27.0" (69 cm)

Shelf Type Wire

Shelf Qty 4

Adjustable Shelves Yes

Thermostat Type Digital

Interior Light Yes

Fan Type Interior

Refrigerant Type R290

Refrigerant Amount 3.5 oz.

Wheels 4

Temperature Range -10 to 25ºF

Sound Level 39 dB

FEATURES

Commercially approved Commercial construction meeting UL commercial listing standards

Complete stainless steel construction Interior and exterior are entirely constructed from stainless steel for lasting durability and easy cleanup

Forced air cooling Top-mounted commercial fan ensures rapid temperature recovery

Automatic defrost with adjustable cycle defrost Adjustable cycle defrost operation ensures the unit avoid temperature spikes and ice buildup

Self-closing door Closes to save energy but will remain open when the door is opened at a 90º angle for easier loading

Open door alarm Alarm will beep 3 times if the door is left open for 30 seconds, 5 times at 60 seconds, and will sound continuously if the door is open for more than 5 minutes

Temperature alarm Visual and audible alarms alert if the interior temperature rises or falls out of set range

Commercial grade casters Ships with a set of casters (2 locking) for easy mobility as needed

Microprocessor control panel Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management

Min/max display Control panel provides a readout of the low and high temperatures in 15 minute increments

Factory-installed lock Keyed lock conveniently located towards the top of the door for added security (2 keys included)

Adjustable plastic-coated wire shelves for improved circulation Multiple shelf positions spaced at 1/2" to allow flexible adjusting to support smaller items

Interior light Energy efficient LED lighting with internal on/off switch

Large capacity 23 cubic feet of storage space inside

Condenser cleaning alarm In order to prevent dust from impeding performance, this unit is equipped with audible and visual alarm that reminds you to clean the condenser every 6 months

Magnetic door gasket Quality door gaskets ensure a tight seal for energy savings and improved performance

Sealed back Space-saving design that ensures easier cleanup

Extended warranty 2 years parts and labor/5 years compressor

Left hand door swing For the same unit with the door opening from the other side, see the SCFF237

Matching refrigerator Pair with SCRR232 for a matching set in stainless steel

Eco-Friendly Using environmentally friendly hydrocarbons refrigerants for a greener footprint

100% CFC free Environmentally friendly design without ozone-damaging chemicals

CARB Compliant Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

DOWNLOADS

BROCHURE w/ DRAWINGS (SCFF237LH.pdf)

TECHNICAL DRAWING (.dwg) (SCFF237LH___AFS23MLLH.__A-C_2019__2.dwg)

REVIT MODEL (Qf_Summit_AFS23ML_Pharma_Lab_All_Freezer_4.rfa)

USE & CARE (SCFF237LH-User-Manual.pdf)

MSDS INFORMATION (XR290a_2.pdf)
