Summit Built-in undercounter ADA height front tap kegerator for commercial or home use, 7.61101e+011, SBC7BRSFRTPADA

Summit's innovative series of commitment-free built-in ADA compliant kegerators offers maximum convenience, eliminating the need to make alterations to countertops while still keeping easy access to beer on tap in commercial and residential settings.

The SBC7BRSFRTPADA is unique because the twin taps are accessed via the unit's front door. The specialized design frees up valuable counter space in kitchens, home bars, and eateries with limited room. The kegerator can be installed under a counter without the need to modify the countertop with a hole for the draft tower. The front tap system also creates a more accessible kegerator experience. This kegerator ships fully assembled and includes a removable stainless steel drip tray that mounts on the door below the taps. Its commercial grade tower has two faucets serving beer from two 1/6 (sixtel) kegs. We also include a CO2 tank, regulator, and all the equipment you need to confidently serve perfectly chilled beer on tap.

Sized with a 24" footprint, this is a versatile front tap beer dispenser that is ETL-S listed to NSF-7 standards for use in commercial environments. At 32" high, it is ideal for installation under lower ADA compliant counters. The stainless steel door includes a full-length handle with a right hand door swing. This unit can be built-in under counters or used freestanding.

The SBC7BRSFRTPADA features a modern black interior liner and stainless steel floor, providing added protection when loading kegs. The interior light, with an on/off rocker switch located behind the dial thermostat, ensures visibility and convenience. Classic mechanical controls guarantee an intuitive, trouble-free performance without any internal boards or chips. The automatic defrost system reduces user maintenance, while our signature cold wall design ensures an efficient, reliable cooling system.

In addition to this dual tap kegerator, our commitment-free line also includes choices that dispense cold brew coffee, as well as model SBC7BRSFLTWADA which features our innovative floating tap design.

Summit also manufactures similar kegerators in standard heights and for outdoor applications. Browse the full Summit product line or contact our product specialists to find the fit for your needs.

SPECIFICATIONS

Overview

Nominal Height 32.0" (81 cm)

Height of Cabinet 31.88" (81 cm)

Height to Hinge Cap 32.0" (81 cm)

Nominal Width 24.0" (61 cm)

Width 23.63" (60 cm)

Nominal Depth 28.0" (71 cm)

Depth 27.38" (70 cm)

Depth with door at 90° 51.88" (132 cm)

Capacity 5.3 cu.ft. (150 L)

Defrost Type Automatic

Door Stainless Steel

Cabinet Black

US Electrical Safety ETL

Canadian Electrical Safety ETL-C

Sanitation ETL-S

Energy Usage/Year 293.0kWh/year

Amps 0.8

Voltage/Frequency 115 V AC/60 Hz

Parts & Labor Warranty 1 Year

Compressor Warranty 5 Years

UPC 761101145440

Kegerator

Door Swing RHD

Reversible Factory Reversible

Height Adjustable Yes

Tap Kit Yes

Number of Taps 2

Thermostat Type Dial

Interior Light Yes

Refrigerant R600a

Refrigerant Amount 0.64 oz.

Inter Height 27.75" (70 cm)

Interior Width 21.0" (53 cm)

Interior Depth 18.0" (46 cm)

Compressor Step Height 5.5" (14 cm)

Compressor Step Width 21.0" (53 cm)

Compressor Step Depth 6.0" (15 cm)

Level Legs Qty 4

Temperature Range 36 to 46°F

FEATURES

24" Wide Front-Tap Beer Dispenser Kegerator includes front taps accessed via the door and includes all of the equipment needed to serve beer from two sixtel kegs

Commitment-free front-taps Unique design requires no alterations to your countertop, freeing up valuable countertop space

Dual tap system Twin draft tower allows you to serve from two 1/6 (sixtel) sized kegs

Built-in capable Designed for installation under the counter

Accessible design Taps are located on the front of the door, requiring no added reach

ADA-compliant height Sized at 32 inches high for installation under lower ADA-compliant counters

Commercially listed ETL-S listed to ANSI-NSF Standard 7 for commercial use

Versatile use Approved for both residential and commercial settings

Complete beer tap kit included Includes a 5 lb. CO2 tank and regulator, dual tap draft arm, Sankey American tap, and the needed connection hardware.

CO2 tank included Full-sized cannister ships with tapping equipment (ships empty)

Interior CO2 holder Bracket is installed inside, allowing you to save on depth by keeping the tank behind your kegs

Automatic defrost No-frost operation for minimum user maintenance

Adjustable mechanical thermostat Simple and intuitive analog controls located inside for easy temperature management

Stainless steel floor cover Interior includes steel cover to protect the floor when loading kegs

Hidden evaporator Cold wall design with hidden evaporator creates a seamless, easy to clean interior

Stainless steel drip tray 2-piece drip tray for easier cleanup

Professional handle Vertically-mounted handle bar in stainless steel

Stainless steel kickplate Attractive finish to match the taps and handle

Fully finished cabinet Allows the dispenser to be used freestanding

Made in Europe & USA Refrigeration unit constructed in Europe then designed and modified in the USA

100% CFC free Environmentally friendly design without ozone-damaging chemicals

CARB compliant Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

DOWNLOADS

BROCHURE w/ DRAWINGS (SBC7BRSFRTPADA.pdf)

TECHNICAL DRAWING (.dwg) (SBC7BRSFRTPADA(2).dwg)

ASSEMBLY DRAWING (SBC7BRSFRTPADA-Assembly.pdf)

USE & CARE (SBC7BRSFRTPADA-User-Manual.pdf)

Energy Guide
