Summit Accucold 160 lb. ice/water dispenser for countertop use, filter kit included, AIWD160FLTR
$6,618.85
Retail Price: $8,660.00
Free shipping
$ 6,618.85
Description
Experience the ultimate in convenience with the commercially approved Accucold countertop water and ice dispenser.
The AIWD160FLTR is ETL-S listed to NSF-12 commercial standards. Measuring just 17.5 inches from the front leg to the unit rear makes this a perfect fit on standard counters, with a slim width under 14 inches. This unit can produce up to 160 pounds of ice per day. Three dispenser functions - ice, water, or ice+water - provide expanded functionality, while the illuminated display ensures easy access and control of the unit.
Adjustable legs offer flexible height options, with a 304 grade stainless steel front complemented by the black dispenser panel and metal cabinet. The removable tray and sealed back make for easy cleaning. This unit comes equipped with UV lighting in the dispenser. The AIWD160FLTR must be used with a drain and should be placed in a space that allows for draining below the unit. It is top vented.
With its countertop footprint and large production output, the AIWD160 is the perfect unit for hospital waiting areas, break rooms, or similar settings looking for a water and ice dispenser that is attractive and efficient. This unit ships with a filter kit. Larger capacity models are also available. Browse the full Accucold ice & water line for more options.
SPECIFICATIONS
Overview
Nominal Height 25.0" (64 cm)
Height of Cabinet 24.75" (63 cm)
Nominal Width 14.0" (36 cm)
Width 13.75" (35 cm)
Nominal Depth 24.0" (61 cm)
Depth 24.0" (61 cm)
Door Black/SS
Cabinet Stainless Steel
US Electrical Safety UL
Canadian Electrical Safety ULC
Sanitation ETL-S
Amps 2.8
Voltage/Frequency 115 V AC/60 Hz
Weight 106.0 lbs. (48 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101086200
Icemaker
Height Adjustable Yes
Drain Required Yes
Daily Ice Production 160.0 lbs. (73 kg)
Ice Storage Capacity 5.3 lbs. (2 kg)
Ice Shape Nugget
Number of Ice Cube Sizes 1
Refrigerant Type R134a
Refrigerant Amount 6.35 oz.
High Side PSI 250.0
Low Side PSI 150.0
Level Legs 4
FEATURES
Commercial Ice/Water Dispenser Full capacity tabletop ice and water dispenser ideal for break rooms, nursing stations, lobbies, and more
Commercially approved ETL-S listed to NSF-12 commercial standards
Filter kit included Commercial grade two-stage filtration kit included to improve the quality and taste of the unit's output
Countertop footprint Makes it the perfect fit for countertops and similar surfaces, with a 17.5" depth from the rear to front legs
Adjustable height Adjustable legs for added convenience
Ice production Large capacity productivity capable of 160 lbs. of ice in a day cycle
Professional look Sleek design in black and stainless steel to complement break rooms, patient care areas, office counters, and more
Nugget ice Produces nugget ice which is slow-melting and easy to chew
Sealed back Save-spacing back allows unit to be flush with the wall, as well as makes cleaning the exterior unit more efficient
Air-cooled condenser Provides an energy efficient, water-saving method to keep the unit cool
UV lighting Dispenser includes built-in UV lighting, as studies have shown this to be an effective tool for eliminating the growth of bacteria
Serviceable through the front door Provides easy, quick access to water and power supplies
Gravity drain Cost-efficient drainage system
Display panel Illuminated display panel for easy use between dispenser functions
Removable tray Can be removed for fast and efficient cleaning.
Ice storage Stores up to 5.3 pounds of nugget ice
Lead-free certified Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
DOWNLOADS
BROCHURE w/ DRAWINGS (AIWD160FLTR.pdf)
TECHNICAL DRAWING (.dwg) (AIWD160_Technical_Drawing.dwg)
ASSEMBLY DRAWING (AIWD160_-Assembly.pdf)
REVIT MODEL (Qf_Summit_AIWD160_Countertop_Ice_and_Water_Dispenser.rfa)
