Summit Commercially listed freestanding all-refrigerator for general purpose use, with front lock, automatic defrost operation and white exterior, 7.61101e+011, FF7LW

Accucold by Summit Appliance offers a wide range of all-refrigerators for general purpose storage. The commercially listed FF7 Series features high performing, perfectly sized all-refrigerators designed for freestanding use.

The FF7LW is a counter height all-refrigerator with a full 5.5 cu.ft. capacity inside a slim 24" footprint. Designed for freestanding use, this model has a white exterior and user-reversible door swing. A factory installed front lock offers convenient security.

Inside, the FF7LW utilizes low maintenance automatic defrost operation. Our unique "hidden" evaporator is set behind the rear wall to create a seamless, easy-to-clean interior that also maximizes shelf space. This unit has a flat door liner that allows it to accept larger trays (up to 19 1/2" x 16"). Adjustable wire shelves allow users to reconfigure the interior to accommodate a variety of sizes. The interior light is controlled by an on/off rocker switch located behind the thermostat dial.

The FF7LW is ETL-S listed to NSF-7 standards for use in commercial establishments. For a built-in version of this unit, see the FF7BI. For more finish options, browse the entire FF7 Series.

NOTE: This unit is designed for general purpose or commercial applications and does not meet DOE energy standards for residential use.

SPECIFICATIONS

Overview

Nominal Height 34.0" (86 cm)

Height of Cabinet 33.5" (85 cm)

Nominal Width 24.0" (61 cm)

Width 23.63" (60 cm)

Nominal Depth 24.0" (61 cm)

Depth 23.5" (60 cm)

Depth with Handle 25.13" (64 cm)

Depth with door at 90° 46.13" (117 cm)

Capacity 5.5 cu.ft. (156 L)

Defrost Type Automatic

Door White

Cabinet White

US Electrical Safety UL

Canadian Electrical Safety ULC

Sanitation ETL-S

Amps 0.8

Voltage/Frequency 115 V AC/60 Hz

Weight 100.0 lbs. (45 kg)

Parts & Labor Warranty 1 Year

Compressor Warranty 5 Years

UPC 761101067414

Refrigerator Features

Door Swing RHD

Reversible Yes

Shelf Type Wire

Shelf Qty 3

Adjustable Shelves Yes

Thermostat Type Dial

Refrigerant Type R600a

Refrigerant Amount 0.64oz.

Level Legs Qty 2

Interior Light Yes

Dimensions

Interior Height 27.75" (70 cm)

Interior Width 20.0" (51 cm)

Interior Depth 17.5" (44 cm)

Compressor Step Height 7.0" (18 cm)

Compressor Step Width 20.0" (51 cm)

Compressor Step Depth 6.0" (15 cm)

FEATURES

Commercially approved ETL-S listed to NSF-7 commercial standards

Fully finished white cabinet Allows the refrigerator to be used freestanding

Front-mounted lock Keyed lock for a secure interior

Automatic defrost operation Reduced user maintenance with automatic defrost

One piece seamless interior liner Enjoy easy clean-up with a one piece liner that won't hold a mess in hidden crevices

Hidden evaporator Cold wall design with hidden evaporator and seamless interior

Deep shelf space Interior accommodates large trays up to 19 1/2" x 15 1/2"

Adjustable shelves Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Interior light on rocker switch Turn the light on when you need it and off when you're done with a convenient rocker switch located just behind the thermostat

Reversible door User-reversible door swing for added flexibility

Adjustable thermostat Dial thermostat located inside for easy temperature management

100% CFC free Environmentally friendly design without ozone-damaging chemicals

CARB Compliant Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
